Normal, Auto Answer Disabled:
provides no auto-answer logic when a fader with
a hybrid assigned is turned
Channel ON Answers Hybrid:
»
has an incoming call, turning its assigned fader
will answer the call.
ON
»
Channel ON or Preview ON Answers Hybrid:
When a hybrid has an incoming call, turning its
assigned fader
ON
key will answer the call.
Preview
•
BACKWARD
FEED
lows you to enable or disable backfeeds to this audio
source.
•
BACKWARD FEED DIM GAIN:
unique to Element: Talkback is sent over dimmed
backfeed audio. If you want a hard interruption
(Talkback interrupts Program audio), set it to maxi-
mum dim, which mutes the audio. But maybe your
jocks would like to just have their program audio
dimmed, and the Talkback come over it so they can
still monitor air while they're being talked to. In this
case, input a value by which the program audio will
be dimmed. Adjustment range is 0dB to -30dB.
•
LOGIC PORT ENABLED/DISABLED:
to enable or disable GPIO machine logic to this au-
dio source device.
•
GPIO READY ENABLED/DISABLED:
vices such as CD players or tape machines to sig-
nal their readiness to the operator through the OFF
button LED. If a device is cueing, its STOP lamp
will not be lit. Tying the device's stop lamp to the
Ready command means that a machine must be cued
and ready before the OFF lamp illuminates.
If
, the OFF lamp illuminates only when the
Enabled
fader is OFF and the Ready command is active on
the GPIO. If
Disabled
normally whenever the fader is turned OFF.
•
FEED TO SOURCE MODE:
associated with this source, this option determines
what content is fed back from the board.
SmartSurface
On.
When a hybrid
or pressing that channel's
ENABLED/DISABLED:
This is a feature
Allows you
Allows de-
, the OFF lamp illuminates
If there is a backfeed
©2008 Axia Audio — Rev. 3.0
»
Auto (Pgm-1/Phone)
(minus the source) when this source's fader is ON,
and feeds the Phone bus (minus the source) when
the fader is OFF. (Program 1 and 2 feeds are post-
fader; Phone feed is pre-fader to allow speaker-
phone style operation thru the Operator's mic.
feeds the Phone bus, minus the source.
»
Phone
feeds the Program 1 bus, minus the
»
PGM1
source.
feeds the Program 2 bus, minus the
PGM2
»
source.
Al-
feeds the Program 3 bus, minus the
PGM3
»
source.
feeds the Program 4 bus, minus the
»
PGM4
source.
AUX SEND A
»
source.
AUX SEND B
»
the source.
»
AUX SEND C
the source.
AUX SEND D
»
the source.
About the PHONE, RECORD and PROGRAM
buses: Element's PGM-4 mix bus is a spe-
cial multi-purpose bus that does several things
at once to make life easier for the operator.
Sources assigned to PGM-4 are also sent to the
RECORD bus, a special post-fader, pre-on/off
output that can be used to feed recording de-
vices.
At the same time, sources assigned to PGM-4
are mixed and sent to the PHONE bus. PHONE is
an internal bus which does not feed a separate
output; instead, it picks up PGM-4 audio pre-
fader and pre-On/Off and backfeeds it callers
(minus themselves, of course) when the channel
is OFF and AUTO is selected as the Feed To
Source Mode.
•
SIGNAL MODE:
treated as mono or stereo, and how.
feeds incoming L/R signal to left and
Stereo
»
right channels of assigned bus(es).
feeds incoming left channel to both chan-
Left
»
nels of assigned bus(es).
feeds incoming right channel to both chan-
»
Right
nels of assigned bus(es).
feeds the Program 1 bus
the Aux Send A bus, minus the
feeds the Aux Send B bus, minus
feeds the Aux Send C bus, minus
feeds the Aux Send D bus, minus
Determines whether source will be
