Chapter 5 – Recording Link
Right-click the default empty link or configured RSS IP address in the
interface, and then click Properties to display the Recording Link -> General
interface.

General Settings

Figure 5-2
The table below explains the detailed meanings of these parameters.
Table 5-1
Parameter
RSS 2000 IP
Address
RSS 2000 Alias
Alias Type

DTMF Code Setting

To set the recording control operations and rights for use by connected
endpoints, click the DTMF Codes tab.
Figure 5-3
5-2
Recording Link - General
Parameter Description for Recording Link - General
Description
Enter the IP address of the RSS 2000 to be connected. This item
is optional if an alias is set in the Alias check box below.
Enter the E.164 number or H.323 alias of the RSS 2000 in
accordance with the selected alias type. This item is optional if
the IP address of the RSS 2000 is set.
Note: If the alias is used for recoding call, both RMX 1000 and
RSS 2000 need to be registered to the same gatekeeper.
Set the alias type of the RSS 2000: H.323 or E.164.
Recording Link - DTMF Codes
