The table below explains the detailed meanings of these parameters.
Table 8-1 Configuration Description of New Participants
Parameter Description
Enter a name to identify the participant.
Name
IP Address/Route
Address
This item is optional if an H.323 alias or SIP address is set in
the Alias/SIP Address option below.
Select the network communication protocol used when the
participant's endpoint dials in to the conference: H.323 or SIP.
Type
The option in the Alias/SIP Address drop-down list will change
along with the network type selected here.
Alias/SIP Address
This item is optional if the IP address of the endpoint is set.
If the device is a standard endpoint, select No Cascade.
If the device will be a cascaded link to another MCU, set the
master/slave relationship of the RMX 1000 relative to the
participant: If the RMX 1000 is the master, select Master,
Cascade
otherwise select Slave. In the cascading mode, you need to
set the following three items: Dialing Direction, Extension, and
Password.
Select the dialing direction:
Dialing Direction
Note: Dialing Direction is available only when the Slave or
Master is selected in Cascade option.
Use this field in case the user would like to send an extension
Extension
field to the remote end.
Enter a DTMF code that will be sent upon connection to the
Password
remote end.
If this option is selected, the participant will be defined as an
audio participant, and the system does not support video input
Audio only
and output capabilities.
To add a participant who must be reached by dialing through a Polycom VBP
(formerly known as V2IU), you need to enter the WAN IP address of the VBP in IP
Address and the E.164 number of the VBP-registered endpoint in Extension.
If the network type is set to H.323, enter the IP address of
the participant's endpoint.
If the network type is set to SIP, enter the route address of
the participant's endpoint.
If the network type is set to H.323, select the alias type of
H.323 or E.164 in the right drop-down list, and then enter the
related alias.
If the network type is set to SIP, select the SIP address type
in the right drop-down list, and then enter the related
address.
Dial-in: The participant's device dials in the conference at the
local RMX 1000.It is unnecessary to set the items Extension
and Password if this option is selected.
Dial-out: The local RMX 1000 dials out to the participant's
device.
