PIPER CHEROKEE SIX SERVICE MANUAL (cont)
LIST OF ILLUSTRATIONS (cont)
Figure
Aerofiche
Grid No.
7A-45.
Checking Harness Lead Continuity ...................................
.
13
7A-46. Checking Harness Lead Insulation Resistance .................................
213
7A-47.
Modified Pliers ...................................
214
7A-48.
Ferrule Positioned Under Braid .........................
2I4
7A-49.
Position of 11-8627 Kit and Contact Spring at Start of Installation .... 2I5
.. 215
7A-50.
Position of 11-8627 Kit and Contact Spring after Installation ....................
2I5
7A-51. Lubricating Sleeve ...................................
....... ...
2I5.
7A-52. Lubricating Ferrule Shoulder ................................
..........
.
2
7A-53.
Removing Spark Plub Frozen to Bushing................
..................
218
8-1.
Fuel System (PA-32-260) ...................................
........ 2I21
8-2.
Fuel System (PA-32-300) ..........................................
2122
8-3. Fuel System (PA-32-300, Serial Nos. 32-7940001 and up; PA-32R-300 All) ........
2123
8-4.
Fuel Gauge (PA-32R-300) ..........................................
. 2J4
8-5.
Fuel Selector and Filter ....................................
2J5
8-6.
Fuel Filter .........................................
.......
8-7. Pulsate (Plunger) Fuel Pump .........................................
2J9
9-1. Instrument Panel (PA-32-260,Serial Nos. 32-1 to 32-1110 incl.,
and PA-32-300, Serial Nos. 32-40000 to 32-40565 incl.) ..................
2J24
9-2.
Instrument Panel (PA-32-260, Serial Nos. 32-1111 to 32-1320) ...................
2K1
9-3.
Instrument Panel (PA-32-300, Serial Nos. 32-40566 to 32-41018) .................
2K2
9-4.
Instrument Panel (PA-32-260, Serial Nos. 32-7100001 to 32-7200055) .............
2K3
9-4a.
Instrument Panel (PA-32-260, Serial Nos. 32-7300001 to 32-7400061) .............
2K4
9-4b.
Instrument Panel (PA-32-300, Serial Nos. 32-7140001 to 32-7240147) .............
K5
9-4c. Instrument Panel (PA-32-300, Serial Nos. 32-7340001 to 32-7440182) .............
K6
9-4d. Instrument Panel (PA-32-260, Serial Nos. 32-7500001 and up) ..................
2K7
9-4e.
Instrument Panel (PA-32-300, Serial Nos. 32-7540001 and up)........
..... .
. 2K8
9-4f.
Instrument Panel (PA-32R-300, Serial Nos. 32R-7680001 and up) ................
2K9
9-5.
Instrument Air System Installation..........................................2K12
10-la. Alternator and Starter System (PA-32-260, Serial Nos. 32-1 to
32-855 inclusive).......................
3A15
10-lb.
Alternator and Starter System (PA-32-260, Serial Nos. 32-856 and up,
PA-32-300, Serial Nos. 32-40000 to 32-40566) .....................
3A16
10- I c. Alternator and Starter System (PA-32-260, Serial Nos. 32-1112 to
32-7400061 incl., and PA-32-300, Serial Nos. 32-40567 to 32-7440182 inc.)
....
3A17
10-2a
Alternator and Starter System (PA-32-260, Serial Nos. 32-7500001 to
32-7600033 incl., and PA-32-300, Serial Nos. 32-7540001 to 32-7640142 incl.,
and PA-32R-300, Serial Nos. 32R-7680001 to 32R-7680538 incl.) ......
... 3A18
10-2b. Alternator and Starter System (PA-32-260, Serial Nos. 32-7700001 to
32-7800008 incl.. PA-32-300, Serial Nos. 32-7740001 and up, and PA-32R-300,
Serial Nos. 32R-7780001 to 32R-7880068) .................................
3A19
