Maximum
TORQUE_PROD_CURRENT_MAX
[1000.0%]
USER_CURRENT_MAX
[1000.0%]
POWER_MAX
[9999.99kW]
The values given in square brackets indicate the absolute maximum value allowed for the variable maximum.
Table 4-2 Maximum motor rated current
200V
Current Max
Size scaling current
(Kc) A rating A
DST1201x 2.92 1.70
DST1202x 6.52 3.80
DST1203x 9.26 5.40
DST1204x 13.03 7.60
4.1.1

Default

The default values given are the standard drive defaults which are
loaded after a drive reset with 1233 in Pr x.00.
4.1.2

Second motor parameter

Some parameters have an equivalent second motor value that can be
used as an alternative when the second motor is selected with Pr 11.45.
Menu 21 contains all the second motor parameters. In this menu the
parameter specifications include the location of the normal motor
parameter which is being duplicated.
4.1.3

Update rate

Defines the rate at which the parameter data is written by the drive
(write) or read and acted upon by the drive (read). Where background
update rate is specified, the update time depends on the drive processor
load. Generally the update time is between 2ms and 30ms, however, the
update time is significantly extended when loading defaults, transferring
data to/from a SMARTCARD, or transferring blocks of parameters or
large communications messages to/from the drive (not a Solutions
Module) via the drive serial comms port.
4.2

Sources and destinations

4.2.1

Sources

Some functions have source pointer parameters, i.e. drive outputs, PID
controller etc.. The source pointer parameter range is Pr 0.00 to
Pr 21.51. The source pointer is set up to point to a parameter, which
supplies the information to control the source and this is referred to as
the source data parameter. For example, Pr 7.19 is the source pointer
parameter for analog output 1. If Pr 7.19 is set to a value of 18.11, then
Pr 18.11 is the source data parameter, and as the value of Pr 18.11 is
modified the analog output level is changed.
1. If the parameter number in the source pointer parameter does not
exist the input is taken as zero.
2. If the source is not a bit type source (i.e. not a digital output etc.)
then the source level is defined by (source data value x 100%) /
source data parameter maximum. Generally the result is rounded
down to the nearest unit, but other rounding effects may occur
depending on the internal scaling of the particular source function.
Digitax ST Advanced User Guide
Issue Number: 1
Parameter description
Parameter x.00
format
Maximum torque producing current
This is used as a maximum for torque and torque producing current parameters. It is
MOTOR1_CURRENT_LIMIT_MAX or MOTOR2_CURRENT_LIMIT_MAX depending on which motor map is
currently active.
Current parameter limit selected by the user
The user can select a maximum for Pr 4.08 (torque reference) and Pr 4.20 (percentage load) to give suitable
scaling for analog I/O with Pr 4.24. This maximum is subject to a limit of MOTOR1_CURRENT_LIMIT_MAX. or
MOTOR2_CURRENT_LIMIT_MAX depending on which motor map is currently active.
USER_CURRENT_MAX = Pr 4.24
Maximum power in kW
The maximum power has been chosen to allow for the maximum power that can be output by the drive with
maximum AC output voltage, maximum controlled current and unity power factor. Therefore
POWER_MAX = √3 x AC_VOLTAGE_MAX x DRIVE_CURRENT_MAX
400V
Current Max
Size scaling current
(Kc) A rating A
DST1401x 2.58 1.50
DST1402x 4.63 2.70
DST1403x 6.86 4.00
DST1404x 10.12 5.90
DST1405x 13.72 8.00
www.controltechniques.com
Advanced parameter Serial comms
descriptions protocol
Definition
3. If the source is a bit, i.e. a digital output, and the source data
parameter is a bit parameter then the input to the source function
follows the value of the source data parameter.
4. If the source is a bit, i.e. a digital output, and the source data
parameter is not a bit parameter the source input is zero if the
source data value is less than source data parameter maximum / 2
rounded down to the nearest unit. The source input is one if the
source data value is greater than or equal to source data parameter
maximum / 2 rounded down to the nearest unit. For example if the
source pointer parameter is set to Pr 18.11, which has a maximum of
32767, the source input is zero if the source data value is less than
16383 and one if it is greater than this.
4.2.2

Destinations

Some functions have destination pointer parameters, i.e. drive inputs,
etc.. The destination pointer parameter range is Pr 0.00 to Pr 21.51. The
destination pointer parameter is set up to point to a parameter, which
receives information from the function referred to as the destination
parameter.
1. If the parameter number in the destination pointer parameter does
not exist then the output value has no effect.
2. If the destination parameter is protected then the output value has
no effect.
3. If the function output is a bit value (i.e. a digital input) the destination
parameter value does not operate in the same way as a source
described above, but is always either 0 or 1 depending on the state
of the function output whether the destination parameter is a bit
parameter or not.
4. If the function output is not a bit value (i.e. analog input) and the
destination parameter is not a bit parameter, the destination value is
given by (function output x destination parameter maximum) / 100%.
Generally the result is rounded down to the nearest unit, but other
rounding effects may occur depending on the internal scaling of the
particular source function (rounded down to nearest unit). Pr 1.36
and Pr 1.37 are a special case. The scaling shown in the description
of parameter Pr 1.08 is used when any non-bit type quantity is
routed to these parameters.
5. If the function output is not a bit value and the destination parameter
is a bit value, the destination value is 0 if the function output is less
than 50% of its maximum value, otherwise it is 1.
6. If more than one destination selector is routed to the same
destination, the value of the destination parameter is undefined. The
drive checks for this condition where the destinations are defined in
any menu except menus 15 to 17. If a conflict occurs a dESt trip
occurs that cannot be reset until the conflict is resolved.
