Summary of Contents for Control Techniques Mini Maestro Drive
- Page 1 User Guide Mini Maestro Drive Variable Speed Drive for Permanent-magnet DC Servo-motors Part Number: 0470-0005 Issue Number: 2...
- Page 2 Safety Information Persons supervising and performing the electrical installation or maintenance of a Drive and/or its external Option Unit must be suitably qualified and competent in these duties. They should be given the opportunity to study and if necessary to discuss this User Guide before work is started.
- Page 3 Copyright © November 1998 Control Techniques Drives Ltd Issue Code: Minu2 Issue Date: November 1998...
- Page 4 Contents Data Mechanical Installation Dimensions of the Drive Mounting location Choke (optional) Electrical Installation Connections Grounding External power supply Motor connections Signal connections Setting up the Drive Adjusting the potentiometers Mounted components Making adjustments to the Drive Motor phasing Dynamic calibration Diagnostics LED indicators Fault finding...
