9.27 Motorized pot down
Bit SP
Coding
1
Default 0
Update rate 4ms x number of menu 9 or 12 functions active read
9.28 Motorized pot reset
Bit SP
Coding
1
Default 0
Update rate 4ms x number of menu 9 or 12 functions active read
These three bits control the motorized pot. The up and down inputs increase and decrease the output at the programmed rate respectively. If both up
and down are active together the up function dominates and the output increases. If the reset input is one, the motorized pot output is reset and held
at 0.0%.
9.29 Binary sum ones input
Bit SP
Coding
1
Default 0
Update rate 4ms x number of menu 9 or 12 functions active read
9.30 Binary sum twos input
Bit SP
Coding
1
Default 0
Update rate 4ms x number of menu 9 or 12 functions active read
9.31 Binary sum fours input
Bit SP
Coding
1
Default 0
Update rate 4ms x number of menu 9 or 12 functions active read
9.32 Binary sum output
Bit SP
Coding
Range 0 to 255
Default 0
Update rate 4ms x number of menu 9 or 12 functions active write
9.33 Binary sum destination
Bit SP
Coding
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on reset
