Control Techniques Digitax ST Advanced User's Manual page 191

Parameter Keypad and
structure display
Display Value
Disabled 0 No event task scheduled
Event 1 EVENT task scheduled
Event1 2 EVENT1 task scheduled
Event2 3 EVENT2 task scheduled
Event3 4 EVENT3 task scheduled
17.36 CTNet diagnostic parameter
Digitax ST Variant Plus
Bit SP
Coding
Update rate 4ms write
The status of the CTNet network is displayed in the CTNet diagnostic parameter. When the Motion Processor is communicating successfully on the
CTNet network the number of messages per second is displayed.
Table 5-13 CTNet diagnostics
Pr 17.36 Status
>0 Network Healthy
Network Healthy,
0
No Data Transfer
-1 RECON
-2 Initialisation Error
-3 MYRECON
17.37 Reject download if drive enabled
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
If this parameter is set, then if the user attempts to download a new user DPL program or operating system to the Motion Processor and the drive is
enabled the download will be rejected and a run-time trip 70 will occur, if the global run-time trip parameter (Pr 17.14) is set.
Since downloading stops normal operations of the Motion Processor it may be considered unsafe to do this if the drive system is running, therefore
setting this parameter will prevent downloading under this condition.
17.38 Do not trip drive on APC run-time error
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
When this parameter is 0 the drive will trip with runtime error 81 if an APC non-recoverable error occurs, such as use of an uninitialized CAM function.
When this parameter is 1 the drive will not trip when an APC non-recoverable error occurs
Digitax ST Advanced User Guide
Issue Number: 1
Parameter
Parameter x.00
description format
Description
FI DE Txt VM DP
Description
Indicates the number of messages per second be processed every
second.
The low-level token ring has been established and is active, but the
node is not receiving any CTNet data messages.
A network reconfiguration has been detected.
The Motion Processor was unable to configure the CTNet interface.
Check that the node address and data rate are set correctly.
The Motion Processor forced a CTNet network reconfiguration
FI DE Txt VM DP
FI DE Txt VM DP
www.controltechniques.com
Advanced parameter Serial comms
descriptions protocol
ND RA NC NV PT US
1 1 1
ND RA NC NV PT US
1
ND RA NC NV PT US
1
Electronic
Performance
nameplate
RW BU PS
1
RW BU PS
1
RW BU PS
1
Menu 17
191
