• A test is performed to ensure that the feedback device direction is correct
• Pr 3.25 (phasing angle) is updated and saved to EEPROM.
This test will operate correctly when the load is an inertia, and although a small amount of cogging and stiction is acceptable, this test cannot be used
for a loaded motor. The test can only be used where the total inertia is less than 0.715 x T
where Trated is the torque produced by rated current as defined by Pr 5.07 or Pr 21.07. In most cases the motor only moves by the required angle,
however, it is possible for the test to initiate additional movement due to cogging torque. The amount of movement depends on the design of the
motor and is similar to the movement produced by cogging torque when the drive is disabled. If the motor is moving at a speed that is higher than the
zero speed threshold (Pr 3.05) when the test is initiated a tunE3 trip is initiated.
This test can be used with any type of encoder except a commutation only encoder i.e. Ab.Servo, Fd.Servo or Fr.Servo encoders with the lines per
rev set to zero. However, it is also not recommended with Ab.Servo, Fd.Servo or Fr.Servo encoders because the absolute position is not defined until
two valid changes of the commutation signals have occurred after power-up or an encoder trip. Therefore if the test is carried out before two valid
changes have occurred, the movement produced during the test may be quite large and the result may be slightly inaccurate. Once two valid changes
have occurred the test operates in the same way as for other encoder types.
The current controllers are used to perform this test, however, the default gains may be too high. It is not possible to carry out the necessary test to
set up the current controllers before the phasing angle is known. If the gains are too high the minimal movement phasing test may cause an OI.AC
trip. If this happens the current controller gains should be reduced progressively until the test is successful. Once the phasing angle is known, the
stationary test to set up the current controller gains only (Pr 5.12=4) may be used to obtain the correct gain values for the current controllers.
6. Current controller gain calculation only
• No current is applied to the motor.
• The current loop gains are calculated based on the value of the motor inductance (Pr 5.24) and resistance (Pr 5.17) and written to Pr 4.13 and
Pr 4.14.
• Pr 4.13 and Pr 4.14 are saved to EEPROM.
This is intended to be used as a method of setting up the current loop gains from user defined values of motor inductance and resistance. The drive
should not be enabled to perform these calculations. If the parameter is set to 6 it is automatically cleared by the drive once the calculation is
complete. It should be noted that the value changes back to zero within a few hundred milliseconds of being set to 6 by the user.
The auto-tune tests may be aborted by removing the run command or the enable or if a trip occurs. During the auto-tune tests the following trips can
occur in addition to the other drive trips.
Trip code
The position feedback did not change
(i.e. motor did not turn or feedback failed)
tunE1
The motor did not reach the required speed
Position feedback direction incorrect
The motor could not be stopped
tunE2
Minimal movement phasing test failed
Drive encoder commutation signals connected
incorrectly, i.e. direction incorrect.
(Drive encoder only.)
tunE3
The motor was moving when the minimal movement
phasing test was initiated
The calculated inertia is out of range
Drive encoder U commutation signal fail
tunE4
(Drive encoder only.)
Drive encoder V commutation signal fail
tunE5
(Drive encoder only.)
Drive encoder W commutation signal fail
tunE6
(Drive encoder only.)
Motor poles or encoder lines set up incorrectly. A trip is
initiated if the speed is not within ±6.25% of the
tunE7 expected no load speed just after the motor has
ramped up to speed. This trip will not occur if the motor
poles are set to more than 12.
tunE Auto-tune stopped before completion
rS* Stator resistance too high
*The rS trip is produced if the drive cannot achieve the necessary current levels to measure the stator resistance during the test (i.e. there is no motor
connected to the drive), or if the necessary current level can be achieved, but the calculated resistance exceeds the maximum values for the
particular drive size or it exceeds the maximum of Pr 5.17. The maximum measurable value for a particular drive size can be calculated from the
following formula.
= DC_VOLTAGE_MAX / Kc / 0.45 / √2
Rs
max
where Kc is the current scaling factor for the drive
Digitax ST Advanced User Guide
Issue Number: 1
Parameter
Parameter x.00
description format
Reason
www.controltechniques.com
Advanced parameter Serial comms
descriptions protocol
/ Pr 5.38 kgm
rated
Test which can cause trip
1,2,5
3
1,2
3
5
1,2
5
3
1,2
1,2
1,2
1,2
All
2
Electronic
Performance
nameplate
2
, assuming no additional stictional load,
