Control Techniques Digitax ST Advanced User's Manual page 97

Parameter Keypad and
structure display
Voltage level
DC_VOLTAGE_MAX
Braking IGBT threshold voltage
Under voltage trip level
Restart voltage level after UV trip
Full scale voltage measurement and the over voltage trip level are defined by DC_VOLTAGE_MAX. However, the maximum level of the low voltage
DC should not normally exceed 90% of this value to avoid spurious over voltage trips.
6.45 Force cooling fan to run at full speed
Bit SP
Coding
1
Update rate Background read
The drive thermal model system normally controls the fan speed, however the fan can be forced to operate at full speed if this parameter is set to 1.
When this is set to 1 the fan remains at full speed until 10s after this parameter is set to zero.
When the drive is in the UV state the fan always runs at minimum.
6.46 Nominal low voltage DC supply
Bit SP
Coding
Range 48 to 72V
Default 48
Update rate Background read
This parameter defines the nominal supply voltage when operating in low voltage mode. The parameter is used to define the braking IGBT switching
threshold and the over voltage trip level for low voltage battery mode (see Pr 6.44).
6.47 Disable mains/phase loss detection from input rectifier
Bit SP
Coding
1
Default 0
Update rate Background read
Digitax ST has a diode rectifier input stage with no direct monitoring system. Mains loss and phase loss detection is derived from the DC bus voltage.
This parameter has no effect.
6.48 Mains loss ride through detection level
Bit SP
Coding
Range 0 to DC_VOLTAGE_SET_MAX V
200V rated drive 205
Default
400V rated drive 410
Update rate Background read
The mains loss detection level can be adjusted using this parameter. If the value is reduced below the default value the default value is used by the
drive. If the level is set too high so that mains loss detection becomes active under normal operating conditions the motor will coast to a stop.
6.49 Disable multi-module drive module number storing on trip
Bit SP
Coding
1
Default 0
Update rate Background read
If Pr 6.49 is zero the module number is stored in the module number and trip time log. If this parameter is one, either the powered-up clock or run time
clock is stored in the module number and trip time log as defined by Pr 6.28. It should be noted that changing this parameter clears the trip, and
module number and trip time logs.
Digitax ST Advanced User Guide
Issue Number: 1
Parameter
Parameter x.00
description format
Pr 6.46 x 1.45
Pr 6.46 x 1.325
36V
40V
FI DE TE VM DP ND
FI DE TE VM DP
FI DE TE VM DP
FI DE TE VM DP
1
FI DE TE VM DP
www.controltechniques.com
Advanced parameter Serial comms
descriptions protocol
RA NC NV PT US RW BU
1 1
ND RA NC NV PT US RW BU PS
1 1
ND RA NC NV PT US RW BU PS
1
ND RA NC NV PT US RW BU PS
1 1
ND RA NC NV PT US RW BU PS
1
Electronic
Performance
nameplate
PS
1 1
1
1 1
1
Menu 6
97
