Parameter
Menu 17
structure
5.18

Menu 17: Motion Processors

Menu 17 parameter functions are dependant on the Digitax ST variant.
5.18.1

Digitax ST Base

Menu 17 not available.
5.18.2

Digitax ST Indexer and Digitax ST Plus

17.01 Motion Processor ID
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range 0 to 599
Update rate 4ms write
17.02 Motion Processor software version
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range 0.00 to 99.99
Update rate 4ms write
17.03 DPL program status
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range None (0), Stop (1), Run (2), Trip (3)
Update rate 4ms write
Provides the run status of the user DPL program in the Motion Processor. The following values are defined:
Display Value
nonE 0 No DPL program present
StoP 1 DPL program is stopped
run 2 DPL program is running
Run-time error. ERROR task running or DPL
triP 3
program stopped
17.04 Available system resource
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range 0 to 100
Update rate 4ms write
Displays the free CPU resource as a percentage of the current background execution time calculated over 200ms.
17.05 RS485 address
Digitax ST Variant Plus
Bit SP
Coding
Range 0 to 255
Default 11
Update rate 4ms write
Defines the address of this node for ANSI and Modbus communications protocols. For the ANSI protocol the address range is 11 to 99 where the first
digit is the group address and the second digit is the unit number. Both digits must be in the range of 1-9. Zero is not permitted since it is used by the
master for addressing groups of nodes. This parameter has no effect if the EIA-RS485 mode is 25 (CTSync) or 26 (CTSync).
182
Keypad and
Parameter x.00
display description format
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
1
Description
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
www.controltechniques.com
Parameter Advanced parameter
descriptions
NC NV PT US RW BU
1 1
NC NV PT US RW BU
1 1
NC NV PT US RW BU
1 1
NC NV PT US RW BU
1 1
NC NV PT US RW BU
1
Serial comms Electronic
protocol nameplate
PS
1
PS
1
PS
PS
1
PS
1 1
Digitax ST Advanced User Guide
Performance
Issue Number: 1
