Control Techniques Digitax ST Advanced User's Manual page 190

Parameter
Menu 17
structure
17.32 CTNet easy mode set-up - Transfer slot 1 destination parameter
Digitax ST Variant Plus
Bit SP
Coding
Range 0 to 9,999
Default 0
Update rate 4ms write
17.33 CTNet easy mode set-up - Transfer slot 2 destination parameter
Digitax ST Variant Plus
Bit SP
Coding
Range 0 to 9,999
Default 0
Update rate 4ms write
17.34 CTNet easy mode set-up - Transfer Motion Processor destination parameter
Digitax ST Variant Plus
Bit SP
Coding
Range 0 to 9,999
Default 0
Update rate 4ms write
Pr 17.26 to Pr 17.34 define the source and destinations for CTNet easy-mode cyclic data.
Parameter Format Channel
Pr 17.26 NNNSS
Pr 17.27 MMPP
Pr 17.28 NNNSS
Pr 17.29 MMPP
Pr 17.30 NNNSS
Pr 17.31 MMPP
Pr 17.32 MMPP
Pr 17.33 MMPP
Pr 17.34 MMPP
17.35 CTNet sync event task ID
Digitax ST Variant Plus
Bit SP
Coding
Range Disabled (0), Event (1), Event1 (2), Event2 (3), Event3 (4)
Default Disabled (0)
Update rate 4ms write
Identifies which of the EVENT tasks will be scheduled when a CTNet synchronization message is received or generated. This sync. is generated by a
master node (which can be this node) on the CTNet network at a fixed time-base. The following values are defined:
190
Keypad and
Parameter x.00
display description format
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
Defines the destination node number and slot
NNN = Node number (0-255)
1
SS = Slot number (1-3)
e.g. A value of 201 means node ID 2, slot 1.
Defines the source drive parameter which is to be transmitted
MM = Menu number
1
PP = Parameter number
e.g. A value of 302 means Pr 3.02 (speed)
2 Destination node number and slot for channel 2
2 Source drive parameter for channel 2
3 Destination node number and slot for channel 3
3 Source drive parameter for channel 3
1 Slot 1 destination parameter for incoming data
2 Slot 2 destination parameter for incoming data
3 Motion Processor destination parameter for incoming data
FI DE Txt VM DP ND RA
1
www.controltechniques.com
Parameter Advanced parameter
descriptions
NC NV PT US RW BU
1
NC NV PT US RW BU
1
NC NV PT US RW BU
1
Description
NC NV PT US RW BU
1
Serial comms Electronic
protocol nameplate
PS
1 1
PS
1 1
PS
1 1
PS
1
Digitax ST Advanced User Guide
Performance
Issue Number: 1
