Control Techniques Digitax ST Advanced User's Manual page 186

Parameter
Menu 17
structure
17.15 Disable reset on trip cleared
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
When this parameter is 0, the Motion Processor will be reset when a drive trip is cleared. When set to 1, the Motion Processor will be unaffected by a
drive trip reset (i.e. continue running)
17.16 Encoder data update rate
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range 0 to 3
Default 0
Update rate 4ms write
Display
APC data and menu 90 encoder parameters are updated
0
every 250µs.
APC data and menu 90 encoder parameters are updated
1
immediately prior to every POS task.
APC data and menu 90 encoder parameters are updated
2
immediately prior to every CLOCK task.
APC data and menu 90 encoder parameters are never
3 updated. If these are never updated, more processor resource
will become free.
17.17 Enable parameter over range trips
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
Defines the action taken if a user DPL program attempts to write an out of range value to a parameter. When set at 1, a run-time trip will occur
(number 44); when set at zero the value will automatically be limited to the maximum/minimum of that parameter.
