Menu 10: Status and trips

10.01
Drive ok
Bit
SP
Coding
1
Update rate
Background write
Indicates the drive is not in the trip state. If Pr 10.36 is one and auto-reset is being used, this bit is not cleared until all auto-resets have been
attempted and the next trip occurs. The control board LED reflects the state of this parameter: LED on continuously = 1, LED flashing = 0.
10.02
Drive active
Bit
SP
Coding
1
Update rate
4ms write
Indicates that the drive inverter is active.
10.03
Zero speed
Bit
SP
Coding
1
Update rate
Background write
Indicates that the absolute value of speed feedback (Pr 3.02) is at or below the zero speed threshold defined by Pr 3.05.
10.04
Running at or below min speed
Bit
SP
Coding
1
Update rate
Background write
In bipolar mode (Pr 1.10 = 1) this parameter is the same as zero speed (Pr 10.03). In unipolar mode this parameter is set if the absolute value of the
speed feedback (Pr 3.02) is at or below (minimum speed + 5rpm). Minimum speed is defined by Pr 1.07. The parameter is only set if the drive is
running.
10.05
Below set speed
Bit
SP
Coding
1
Update rate
Background write
10.06
At speed
Bit
SP
Coding
1
Update rate
Background write
10.07
Above set speed
Bit
SP
Coding
1
Update rate
Background write
These flags are set by the speed detector in menu 3.
See Pr 3.06, Pr 3.07 on page 45 and Pr 3.09 on page 46.
10.08
Load reached
Bit
SP
Coding
1
Update rate
Background write
Indicates that the modulus of the active current is greater or equal to the rated active current as defined in menu 4.
