Menu 22: Additional menu 0 set-up

Menu 22 contains parameters that are used to set up the source parameters for menu 0 in addition to those that are set up from within Menu 11.
22.01 to 22.07
22.10 to 22.11
Parameter 00.xy set-up
22.18
22.20 to 22.29
Bit SP
Coding
Range Pr 1.00 to Pr 21.51
Default See Table 5-15
Update rate Background read
These parameters define the parameters that reside in the programmable area in menu 0.
Table 5-15 Menu 22 default settings
Menu 0
Parameter
parameter
Pr 22.01 Pr 031
Pr 22.02 Pr 0.32
Pr 22.03 Pr 0.33
Pr 22.04 Pr 0.34
Pr 22.05 Pr 0.35
Pr 22.06 Pr 0.36
Pr 22.07 Pr 0.37
Pr 22.10 Pr 0.40
Pr 22.11 Pr 0.41
Pr 22.18 Pr 0.48
Pr 22.20 Pr 0.50
Pr 22.21 Pr 0.51
Pr 22.22 Pr 0.52
Pr 22.23 Pr 0.53
Pr 22.24 Pr 0.54
Pr 22.25 Pr 0.55
Pr 22.26 Pr 0.56
Pr 22.27 Pr 0.57
Pr 22.28 Pr 0.58
Pr 22.29 Pr 0.59
It should be noted that if the parameter values saved in the drive EEPROM or on a SMARTCARD are all zero for menu 22 the drive will automatically
load defaults for this menu when the drive is powered up or the parameters are transferred from the SMARTCARD. This ensures that defaults are
used for this menu if the saved parameters are from a software version which did not include this menu.
208
Keypad and
Parameter x.00
display
FI DE Txt VM DP ND
2
Default setting
Pr 11.33
Pr 11.32
Pr 0.00
Pr 11.30
Pr 11.24
Pr 11.25
Pr 11.23
Pr 5.12
Pr 5.18
Pr 11.31
Pr 11.29
Pr 10.37
Pr 0.00
Pr 0.00
Pr 0.00
Pr 0.00
Pr 0.00
Pr 0.00
Pr 0.00
Pr 0.00
