Parameter
Menu 17
structure
17.51 Motion Processor software sub-version
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range 0 to 99
Update rate 4ms write
Specifies the minor revision number of the operating system of the Motion Processor. Use in conjunction with Pr 17.02 to form the complete version
number.
5.18.3

Digitax ST EZMotion

17.01 Motion Processor ID
Bit
Coding
Range 0 to 599
Update rate Write on power-up
17.02 Motion Processor software version
Bit
Coding
Range 00.00 to 99.99
Update rate Write on power-up
17.13 EZOutput 1 Status
Bit
Coding
1
Update rate Trajectory update rate (user configured)
This parameter shows the status of digital output 1 on the Motion Processor. A value of 1 indicates that the output is active. A value of 0 indicates that
the output is inactive. This equates Pin 6 on the EZMotion I/O Connector.
17.14 EZOutput 2 Status
Bit
Coding
1
Update rate Trajectory update rate (user configured)
This parameter shows the status of digital output 2 on the Motion Processor. A value of 1 indicates that the output is active. A value of 0 indicates that
the output is inactive. This equates Pin 7 on the EZMotion I/O Connector.
17.17 EZInput 1 Status
Bit SP
Coding
1
Update rate Trajectory update rate (user configured)
This parameter shows the status of digital input 1 on the Motion Processor. A value of 1 indicates that the input is active. A value of 0 indicates that
the input is inactive. This equates Pin 2 on the EZMotion I/O Connector.
17.18 EZInput 2 Status
Bit SP
Coding
1
Update rate Trajectory update rate (user configured)
This parameter shows the status of digital input 2 on the Motion Processor. A value of 1 indicates that the input is active. A value of 0 indicates that
the input is inactive. This equates Pin 3 on the EZMotion I/O Connector.
194
Keypad and
Parameter x.00
display
FI DE Txt VM DP
SP FI DE Txt VM DP
SP FI DE Txt VM DP
2
SP FI DE Txt VM DP
SP FI DE Txt VM DP
FI DE Txt VM DP
FI DE Txt VM DP
www.controltechniques.com
Parameter Advanced parameter
description format descriptions
ND RA NC NV PT US
1 1
ND RA NC NV PT US RW BU
1 1 1
ND RA NC NV PT US RW BU
1 1 1
ND RA NC NV PT US RW BU
1 1 1
ND RA NC NV PT US RW BU
1 1 1
ND RA NC NV PT US RW BU
1 1 1
ND RA NC NV PT US RW BU
1 1 1
Serial comms Electronic
protocol nameplate
RW BU PS
1
PS
1
PS
1
PS
PS
PS
PS
Digitax ST Advanced User Guide
Performance
Issue Number: 1
