Control Techniques Digitax ST Advanced User's Manual page 204

Parameter
Menu 21
structure
21.09 Rated voltage
Bit SP
Coding
Range 0 to AC_VOLTAGE_SET_MAX V
200V rating drive: 230V
Default
400V rating drive: EUR: 400V, USA: 460V
Normal
Pr 5.09
parameter
Update rate Level 4 read
21.11 Number of motor poles
Bit SP
Coding
Range 0 to 60 (Auto to 120 POLE)
Default 3 (6 POLE)
Normal
Pr 5.11
parameter
Update rate Background read
21.12 Stator resistance
Bit SP
Coding
Range 0.000 to 65.000 x10Ω
Default 0.000
Normal
Pr 5.17
parameter
Update rate Background read
Pr 21.12 shows the stator resistance of the motor divided by 10. Therefore 1.000 in this parameter represents the resistance of 10 Ohms.
Transient inductance (σL
21.14
Bit SP
Coding
Range 0.000 to 500.000 mH
Default 0.000
Normal
Pr 5.24
parameter
Update rate Background read
21.15 Motor 2 active
Bit SP
Coding
1
Default 1
Normal motor
Pr 21.15
parameter
Update rate Background write
Pr 21.15 does not have an equivalent normal motor parameter, but shows when motor 2 is active.
204
Keypad and
Parameter x.00
display
FI DE Txt VM DP ND
1
FI DE Txt VM DP ND
1
FI DE Txt VM DP ND
3
)
s
FI DE Txt VM DP ND
3
FI DE Txt VM DP ND
1
www.controltechniques.com
Parameter Advanced parameter
description format descriptions
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1
Serial comms Electronic
protocol nameplate
PS
1
PS
1
PS
1
PS
1
PS
Digitax ST Advanced User Guide
Issue Number: 1
Performance
