Parameter
Menu 8
structure
Table 5-7 Drive digital I/O terminal, enable input and relay
Terminal + type
T24 input / output 1
T25 input / output 2
T26 input / output 3
T27 input 4
T28 input 5
T29 input 6
T41 / 42 Relay
T22 24V output
T31 SAFE TORQUE OFF
(SECURE DISABLE)
8.01 T24 digital I/O 1 state
8.02 T25 digital I/O 2 state
8.03 T26 digital I/O 3 state
8.04 T27 digital input 4 state
8.05 T28 digital input 5 state
8.06 T29 digital input 6 state
8.07 Relay status
8.08 T22 24V output state
8.09 Drive enable indicator
Bit SP
Coding
1
Default See table
Update rate 4ms write
OFF (0) = Terminal inactive
On (1) = Terminal active
8.10 Drive enable mode select
Coding Bit SP
1
Default OFF (0)
Update rate Background read
Digitax ST has a dedicated hardware enable/SAFE TORQUE OFF (SECURE DISABLE) input which always controls Pr 6.29. If the enable is inactive
the IGBT firing signals are turned off without software intervention. As default (Pr 8.10 = 0) the drive is in the inhibit mode when the enable is inactive.
Setting this parameter to one causes the enable to behave as an Et trip input. When the input becomes inactive an Et trip is initiated. This does not
affect Pr 10.32 (Et trip parameter), therefore an Et trip can be initiated in this mode either by making the enable inactive or setting Pr 10.32 to one.
112
Keypad and
Parameter x.00
display
I/O state Invert
Pr Pr Default
Pr 8.01 Pr 8.11
Pr 8.02 Pr 8.12
Pr 8.03 Pr 8.13
Pr 8.04 Pr 8.14
Pr 8.05 Pr 8.15
Pr 8.06 Pr 8.16
Pr 8.07 Pr 8.17
Pr 8.08 Pr 8.18
Pr 8.09
FI DE Txt VM DP ND
1
FI DE Txt VM DP ND
www.controltechniques.com
Parameter Advanced parameter
description format descriptions
Source / destination
Pr
0 Pr 8.21 Pr 10.03 - Zero speed
0 Pr 8.22 Pr 10.33 - Drive reset
0 Pr 8.23 Pr 6.30 - Run forward
0 Pr 8.24 Pr 6.32 - Run reverse
0 Pr 8.25 Pr 1.41 – Local/remote
0 Pr 8.26
0 Pr 8.27 Pr 10.01 – Drive ok
1 Pr 8.28
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1
Serial comms Electronic
protocol nameplate
Default
Pr 8.31
Pr 8.32
Pr 8.33
Pr 6.31 – Jog
Pr 0.00
PS
PS
1
Digitax ST Advanced User Guide
Performance
Output select
Pr Default
1
0
0
Issue Number: 1
