17.07 RS485 baud rate
Digitax ST Variant Plus
Bit SP
Coding
300 (0), 600 (1), 1200 (2), 2400 (3), 4800 (4), 9600 (5), 19200 (6), 38400 (7), 57600 (8),
Range
115200 (9) baud
Default 4800 (4)
Update rate 4ms write
Defines the baud-rate (or bits-per-second) for the on-board EIA-RS485 port. The following are supported:
Note that this parameter is not relevant when the EIA-RS485 port mode is set to 25 (CTSync Master) or 26 (CTSync Slave).
Display Value
300
600
1200
2400
4800
9600
19200
38400
57600
115200
17.08 RS485 Turnaround delay
Digitax ST Variant Plus
Bit SP
Coding
Range 0 to 255ms
Default 2
Update rate 4ms write
Defines a fixed delay between receiving a message on the EIA-RS485 port and the response being transmitted. This can be useful in 2-wire
configurations where it takes a finite time for the master (host) to switch from transmit mode to receive mode. There is always at least a 1ms delay
and this parameter can be used to extend it.
17.09 RS485 Tx enable delay
Digitax ST Variant Plus
Bit SP
Coding
Range 0 to 1ms
Default 0
Update rate 4ms write
This parameter allows a 1ms delay to be introduced between the Motion Processor enabling the EIA-RS485 transmitter and actually commencing the
transmission. This should only be required if it is found that the recipient of the transmission is receiving a corrupted start of message.
17.10 DPL Print Routing
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range SYPT: OFF (0), RS485: On (1)
Default SYPT: OFF (0)
Update rate 4ms write
This parameter is available on Digitax ST Indexer but is not allowed to be set to a 1 (On). Controls where the output of the DPL PRINT command is
sent. If set to zero (Off), the output is sent to the programming client (SyPTPro) and if set to 1 (On) it will be sent to the EIA-RS485 port.
