8.11 T24 digital I/O 1 invert
8.12 T25 digital I/O 2 invert
8.13 T26 digital I/O 3 invert
8.14 T27 digital input 4 invert
8.15 T28 digital input 5 invert
8.16 T29 digital input 6 invert
8.17 Relay source invert
8.18 T22 24V output source invert
Bit SP
Coding
1
Default Pr 8.11 to Pr 8.17 = OFF (0), Pr 8.18 = On (1)
Update rate 4ms read
OFF (0) = Non-inverted
On (1) = Inverted
8.20 Digital I/O read word
Bit SP
Coding
Range 0 to 511
Update rate Background write
This word is used to determine the status of the digital I/O by reading one parameter. The bits in this word reflect the state of Pr 8.01 to Pr 8.09.
Bit Digital I/O
0 T24 input / output 1
1 T25 input / output 2
2 T26 input / output 3
3 T27 input 4
4 T28 input 5
5 T29 input 6
6 Relay
7 T22 24V output
SAFE TORQUE OFF
8
(SECURE DISABLE)
8.21 T24 digital I/O 1 source/destination
8.22 T25 digital I/O 2 source/destination
8.23 T26 digital I/O 3 source/destination
8.24 T27 digital input 4 destination
8.25 T28 digital input 5 destination
8.26 T29 digital input 6 destination
Bit SP
Coding
Default See Table 5-7 on page 112
Range Pr 0.00 to Pr 21.51
Update rate Read on drive reset
