Control Techniques Digitax ST Advanced User's Manual page 192

Parameter
Menu 17
structure
17.39 Inter-UT70 synchronization status
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range 0 to 3
Default 0
Update rate 4ms write
This parameter displays the current Motion Processor's synchronization status.
Synchronisation
Status
The synchronisation master request is zero or another Solutions
0
Module is synchronisation master.
1 The Motion Processor is synchronisation master.
The Motion Processor is synchronisation master, but the
3
synchronisation frequency is out of specification or not present.
17.40 Inter-UT70 master transfer mode
Digitax ST Variant Indexer, Plus
Bit SP
Coding
Range 0 to 10
Default 1
Update rate 4ms write
17.42 Freeze main drive position
Digitax ST Variant Plus
Bit SP
Coding
1
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
When this parameter is ON (1), the voltage on the Motion Processor digital input 0 (zero) is passed through to the drive's internal Freeze line. This
can be seen by other classes of SM-Solutions modules. For further information on Freeze input, refer to Chapter 8 Freeze and Marker in the SM-
Applications Modules and Motion Processors User Guide.
17.43 Freeze invert
Digitax ST Variant Indexer, Plus
Bit SP
Coding
1
Range OFF (0) or On (1)
Default OFF (0)
Update rate 4ms write
When this parameter is set to zero a freeze occurs on the rising edge of the freeze signal. When it is set to 1 a freeze occurs on the falling edge of
freeze signal. For further information on Freeze input, refer to Chapter 8 Freeze and Marker in the SM-Applications Modules and Motion Processors
User Guide.
When this parameter is set to zero the Motion Processor will freeze data when it sees a rising edge of a freeze pulse from the drive. When it is set to
a 1 the Motion Processor will freeze data when it sees a falling edge of a freeze pulse from the drive. For further information on Freeze input, refer to
Chapter 8 Freeze and Marker in the SM-Applications Modules and Motion Processors User Guide.
192
Keypad and
Parameter x.00
display description format
FI DE Txt VM DP ND RA
Status
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
FI DE Txt VM DP ND RA
www.controltechniques.com
Parameter Advanced parameter
descriptions
NC NV PT US RW BU
1 1
NC NV PT US RW BU
1
NC NV PT US RW BU
1
NC NV PT US RW BU
1
Serial comms Electronic
protocol nameplate
PS
1
PS
1 1
PS
1
PS
1
Digitax ST Advanced User Guide
Performance
Issue Number: 1
