The bit parameters with lower numbers have priority over those with higher numbers.
Pr 1.49 and Pr 1.50 then define the reference as follows:
Pr 1.49 Pr 1.50
1 1
1 >1
2 1
2 >1
3 x
4 x
5 x
Keypad reference
If Keypad reference is selected the drive sequencer is controlled directly by the keypad keys and the keypad reference parameter (Pr 1.17) is
selected. The sequencing bits, Pr 6.30 to Pr 6.34, have no effect and jog is disabled.
Reference selected by timer
The presets are selected automatically in turn. Pr 1.16 defines the time between each change.
21.04 Acceleration rate
Bit SP
Coding
Range 0.000 to 3200.000 s/1000rpm
Default 0.200
Normal
Pr 2.11
parameter
Update rate Background read
21.05 Deceleration rate
Bit SP
Coding
Range 0.000 to 3200.000 s/1000rpm
Default 0.200
Normal
Pr 2.21
parameter
Update rate Background read
21.07 Rated current
Bit SP
Coding
Range 0 to RATED_CURRENT_MAX A
Default Maximum current (i.e. the value of Pr 11.32)
Normal
Pr 5.07
parameter
Update rate Background read
21.08 Rated speed
Bit SP
Coding
Range 0.00 to 40,000.00 rpm
Default 3000.00
Normal
Pr 5.08
parameter
Update rate Background read
