5 Advanced parameter
descriptions
5.1

Overview

Table 5-1 Menu descriptions
Menu no.
1 Speed reference
2 Ramps
3 Speed feedback and speed control
4 Torque and current control
5 Motor control
6 Sequencer and clock
7 Analog I/O
8 Digital I/O
9 Programmable logic, motorized pot and binary sum
10 Status and trips
11 General drive set-up
12 Threshold detectors, variable selectors and brake control
13 Position control
14 User PID controller
15, 16 Solutions Module slots
17 Motion processors
18 Application menu 1
19 Application menu 2
20 Application menu 3
21 Second motor parameters
22 Additional menu 0 set-up
Table 5-2 gives a full key of the coding which appears in the following
parameter tables.
Digitax ST Advanced User Guide
Issue Number: 1
Parameter description
Parameter x.00
format
Description
www.controltechniques.com
Advanced parameter Serial comms
descriptions protocol
Table 5-2 Key to parameter coding
Coding
Bit 1 bit parameter
SP Spare: not used
Filtered: some parameters which can have rapidly changing
FI values are filtered when displayed on the drive keypad for
easy viewing.
Destination: indicates that this parameter can be a
DE
destination parameter.
Txt Text: the parameter uses text strings instead of numbers.
VM Variable maximum: the maximum of this parameter can vary.
Decimal place: indicates the number of decimal places used
DP
by this parameter.
No default: when defaults are loaded (except when the drive
ND is manufactured or on EEPROM failure) this parameter is not
modified.
Rating dependent: this parameter is likely to have different
values and ranges with drives of different voltage and current
ratings. Parameters with this attribute will not be transferred
RA
to the destination drive by SMARTCARDs when the rating of
the destination drive is different from the source drive and the
file is a parameter file.
Not copied: not transferred to or from SMARTCARDs during
NC
copying.
NV Not visible: not visible on the keypad.
PT Protected: cannot be used as a destination.
User save: saved in drive EEPROM when the user initiates a
US
parameter save.
RW Read/write: can be written by the user.
Bit default one/unsigned: Bit parameters with this flag set to
one have a default of one (all other bit parameters have a
BU
default of zero. Non-bit parameters are unipolar if this flag is
one.
Power-down save: parameter automatically saved in drive
EEPROM when the under volts (UV) trip occurs. Power-
PS
down save parameters are also saved in the drive when the
user initiates a parameter save.
Electronic
Performance
nameplate
Attribute
