6.7

Unlocking a security code

1. Select a parameter to be edited
01
2. Press the MODE key. The right hand display will flash CodE
01 CodE
3. Press the
show Co
Co
4. Press the MODE key.
5. If the security code has been entered correctly then the display will show
01
6. If the security code has been entered incorrectly then the display will go back to
Parameter View mode
01
7. Go back to point 2 and enter the correct security code.
8. To relock the security code, set parameter 10 to Loc and press the STOP/RESET
key.
10
6.8

Set security back to zero (0) - no security

1. Unlock the previously entered security code using the previous procedure.
2. Set parameter 10 to L2.
3. Go to parameter 25
4. Press mode key 4 times. This saves the security code to the value 0
5. Set parameter 10 to Loc and press the STOP/RESET key.
If the security code has been lost or forgotten, please contact your local Drive
NOTE
Centre or Distributor.
6.9

Setting to default values

To set the Drive back to default values, set parameter 29 to Eur to load 50Hz defaults
or USA to load 60Hz defaults. Press the MODE key and then the STOP/RESET key
for 1 second. When the default parameters have been set, the display will show the
status of the Drive and the parameter number will return to 01.
6.10

Level 1 and level 2 parameter descriptions

6.10.1Parameter codes/limitations
The key to the parameter codes/limitations in the following Tables is listed below:
1 RW
2 RO
3 Bit
4 B
5 U
6 T
R
7
8 S
38
0.0
or keys to set the security code. The left hand display will
5
0.0
Parameters can now be adjusted
0.0
Loc
Read/Write
Read Only
Two state only parameter, OFF or ON
Bipolar - can have positive or negative values
Unipolar - can have positive values only
Parameter value is represented on the display with a string of Text
Reset required to implement change
Saved on power down
