Control Techniques Digitax ST Advanced User's Manual page 139

Parameter Keypad and
structure display
Table 5-10 Hardware fault trips
HF fault
code
01 CPU address error
02 DMAC address error
03 Illegal instruction
04 Illegal slot instruction
05 Undefined exception
06 Reserved exception
07 Watchdog failure
08 Level 4 crash
09 Heap overflow
10 Router error
Access to the EEPROM failed or incorrect EEPROMs
11
installed.
12 Main program stack overflow
The drive firmware is not compatible with the drive
13
hardware
14-16 Not used
17 Power circuit - Multi-module system thermistor short circuit
Power circuit - Multi-module system interconnect cable
18
error
19 Power circuit temperature feedback multiplexor failure
20 Power circuit - identification code error
21 Power circuit - unrecognised frame size
22 Power circuit - multi-module frame size mismatch
23 Power circuit - multi-module voltage rating mismatch
24 Power circuit - unrecognised drive size
25 Current feedback offset error
Soft start relay failed to close, or soft start monitor failed, or
26
braking IGBT short circuit at power-up
27 Power circuit thermistor 1 fault
Power circuit thermistor 2 or 3 fault / Internal fan fault for
28
some drive sizes.
29 Control board thermistor fault
30 DCCT wired break trip from power module
31 Aux fan failure from power module
32 Identification and trip information serial code
10.30 Full power braking time
Bit SP
Coding
Range 0.00 to 400.00 s
Default See table below
Update rate Background read
This parameter defines the time period that the braking resistor installed can stand full braking volts without damage. The setting of this parameter is
used in determining the braking overload time.
For DST1xxxx drives the default value is a suitable value for standard braking resistors that can be mounted within the drive as given in the table
below.
Drive voltage rating
200V
400V
If Pr 10.30 is set to zero then the braking resistor thermal protection system is disabled.
Digitax ST Advanced User Guide
Issue Number: 1
Parameter
Parameter x.00
description format
Reason for trip
FI DE Txt VM DP ND
2
Parameter default Full braking volts
0.06s
0.01s
www.controltechniques.com
Advanced parameter Serial comms
descriptions protocol
RA NC NV PT US RW BU
1 1
390V
780V
Electronic
Performance
nameplate
PS
1
Menu 10
