8 In the MPTS Dejitter field, the user can choose the following mode for MPTS
Dejitter,

One Stream

Break Into SPTS.

The Ref is 0.
Note: If you have a stat-muxed stream, we recommend "One Stream.
9 Enter the starting and ending rows where you want your settings to be applied.
10 Click Implement Rules to apply settings.
11 Click Save.

MPTS Pass-Through Mode of Operation

Table based Video Operation can be used generically to enable MPTS Pass Through
for broadcast applications.

Individual PIDs can be blocked as required in the Advanced Settings
window. The PAT is blocked using default PID 0.

If TSIDs are provisioned and the PAT is not blocked, the RF Gateway 1 will
pass through the incoming source stream as is.
Note: TSIDs are entered individually for all streams if the PAT is blocked.
78-4025112-01 Rev H0
Provisioning
95
