6.0 Configuration
QoS: Quality of Service is
applied to networks where it
is desired to give particular
data traffic/protocol(s) priority
over other data traffic.
© Microhard Systems Inc.

6.1.4.6 Quality of Service

Quality of Service (QoS) may be applied to various data which enter
the IP Series. This section describes configuring QoS for data which
enters via the ethernet port.
Image 6M: Network Configuration, Quality of Service Submenu
If Enabled, the defined protocols and ports will have the QoS
service applied to them.
To define particular ports, protocol, and priority to be assigned, see
the example of such a configuration exercise on the following page.
CONFIDENTIAL
IP9xx Series
Quality of Service Status
Values
Disable
Disable
Enable
