Appendix D: Approved Antennas - Microhard Systems IP-921 Operating Manual

Appendix D: Approved Antennas

Group Part Number
Quarter Wave
MHS031010
MHS031020
MHS031030
MHS031040
MHS031050
MHS031060
Rubber Ducky
MHS031000
MHS031070
MHS031080
Transit Antennas
MHS031210
MHS031220
MHS031230
MHS031240
Yagi Antennas
MHS031311
MHS031431
MHS031501
MHS031441
MHS031451
MHS031401
MHS031411
Omni Directional
MHS031251
MHS031461
MHS031321
MHS031471
Changes or modifications not expressly approved by Microhard Systems Inc. could void the
user's authority to operate the equipment. This device has been tested with MCX and Reverse
Polarity SMA connectors with the antennas listed in Appendix A When integrated in OEM prod-
ucts, fixed antennas require installation preventing end-users from replacing them with non-
approved antennas. Antennas not listed in the tables must be tested to comply with FCC Section
15.203 (unique antenna connectors) and Section 15.247 (emissions). Please Contact Microhard
Systems Inc. if you need more information.
© Microhard Systems Inc.
Description
<1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Right Angle
<1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Straight
<1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Right Angle MHS
<1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Straight MHS
<1.5dBi, 900MHz 1/4 Wave Antenna MCX Right Angle MHS
<1.5dBi, 900MHz 1/4 Wave Antenna Reverse SMA Straight
2dBi, 900MHz Rubber Ducky Antenna RPTNC Swivel
2dBi, 900MHz Rubber Ducky Antenna Reverse SMA Swivel
2dBi, 900MHz Rubber Ducky Antenna Reverse SMA Straight
3dBd, 900 MHz Transit Antenna with Ground Plane
3dBd, 900MHz Transit Antenna No Ground Plane
3dBd, 900MHz Transit Antenna Permanent Mount GP
3dBd, 900MHz Transit Antenna Permanent Mount NGP
Mounts for Transit Antennas have a RPTNC Pigtail
6dBd, 900MHz Yagi Directional Antenna Antenex, RPTNC Pigtail
6.5dBd, 900MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
9dBd, 900MHz Yagi Directional Antenna Antenex, RPTNC Pigtail
10dBd, 900 MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
11dBd, 900 MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
12dBd, 900MHz Yagi Directional Antenna Antenex, RPTNC Pigtail
12dBd, 900MHz Yagi Directional Antenna Bluewave, RPTNC Pigtail
3dBd, 900MHz Omni Directional Antenna Antenex, RPTNC Pigtail
3dBd, 900 MHz Omni Directional Antenna Bluewave, RPTNC Pigtail
6dBd, 900MHz Omni Directional Antenna Antenex, RPTNC Pigtail
6dBd, 900 MHz Omni Directional Antenna Bluewave, RPTNC Pigtail
WARNING:
CONFIDENTIAL
IP9xx Series
168
