6.0 Configuration
The protocol selected in the
IP Protocol Config field will
determine which configuration
options appear
remainder of the
Configuration Menu.
UDP: User
Protocol does not provide
sequencing information
the packets sent nor does it
e s t a b l i s h
'connection' (‗handshaking')
and is therefore most suited
to communicating
packets of data.
TCP: Transmission Control
Protocol in contrast to UDP
does provide
information and is connection-
oriented; a more
protocol, particularly
large amounts of data are
being communicated.
Requires more
than UDP.
© Microhard Systems Inc.
This setting determines which protocol the serial server will use to
transmit serial port data over the IP Series network.
TCP Client: When TCP Client is selected and data is received on
its serial port, the IP Series takes the initiative to find and connect to
a remote TCP server. The TCP session is terminated by this same
in the
unit when the data exchange session is completed and the
COMn
connection timeout has expired. If a TCP connection cannot be
established, the serial port data is discarded.
Datagram
for
a
small
connection is
serial
sequencing
TCP Server:
session, rather, it will wait for a Client to request a session of it (it's
being the Server—it ‗serves' a Client). The unit will ‗listen' on a
reliable
when
specific TCP port. If a session is established, data will flow from the
Client to the Server, and, if present, from the Server to the Client. If
a session is not established, both Client-side serial data, and
Server-side serial data , if present, will be discarded.
bandwidth

Remote Server Address
IP address of a TCP server which is ready to
accept serial port data through a TCP connection.
For example, this server may reside on a LAN
network server.
Default: 0.0.0.0

Remote Server Port
A TCP port which the remote server listens to,
awaiting a session connection request from the
TCP Client. Once the session is established, the
serial port data is communicated from the Client to
the Server.
Default: 20001

Outgoing Connection Timeout
This parameter determines when the IP Series will
terminate the TCP connection if the
in an idle state (i.e. no data traffic on the
port).
Default: 60 (seconds)
In this mode, the IP Series will not INITIATE a

Local Listening Port
The TCP port which the Server listens to. It allows
a TCP connection to be created by a TCP Client to
carry serial port data.
Default: 20001
CONFIDENTIAL
IP9xx Series
IP Protocol Config
continued...
