Microhard Systems IP-921 Operating Manual page 126

6.0 Configuration
© Microhard Systems Inc.
Select the zone which is to be the source of the data traffic. WAN
applies to the wired connection and LAN to the wireless, on all IP
Series units, whether a Master, Repeater, or Remote.
If a valid IP address is specified, the action will apply against that
address; otherwise, leaving the default value of 0.0.0.0 in this field
results in the action applying to all source IP addresses.
Select the zone which is the intended desination of the data traffic.
WAN applies to the wired connection and LAN to the wireless, on
all IP Series units, whether a Master, Repeater, or Remote.
CONFIDENTIAL
IP9xx Series
Source Zone
Values
WAN
LAN
FW
VPN
all
Source IP
Values
0.0.0.0
valid IP address
Destination Zone
Values
WAN
LAN
FW
VPN
all
126
