6.0 Configuration
If the Operation Mode is set
to MASTER, the Unit Address
field will NOT be displayed in
the Radio Configuration
menu.
By setting the unit to Master,
its Unit Address will be 1.
FCC regulations allow for
up to 36dBi
isotropic radiated
(EIRP). The sum (in dBm)
of the transmitted power,
the cabling loss, and the
antenna gain
exceed 36dBi.
© Microhard Systems Inc.
The unit address is, and must be, a unique identifier of each
modem in a network.
The Master has by default, and must retain, a unit address of 1;
65535 is the broadcast address.
This setting establishes the transmit power level which will be
presented to the antenna connector at the rear of the IP Series.
Unless required, the RF Output Power should be set not for
maximum, but rather for the minimum value required to maintain an
adequate system fade margin.
effective
power
cannot
CONFIDENTIAL
IP9xx Series
Unit Address
Values
number varies
2-65534
RF Output Power
Values
dBm (mW equivalent)
20 (100)
21 (125)
22 (160)
23 (200)
24 (250)
25 (320)
26 (400)
27 (500)
28 (630)
29 (800)
30 (1000)
