Microhard Systems IP-921 Operating Manual page 152

6.0 Configuration
There is a PING tool which
may be found via the Text UI
(System Tools Menu) which is
not available in the Web UI.
© Microhard Systems Inc.
Image 6AX: Text User Interface, Main Menu
Upon successful login, the above Main Menu will appear.
Refer to the detailed information within the Web User Interface
section (6.1) of this manual for a detailed explanation of all of
the configuration options.
Web UI are available via the Text UI.
An advantage of using the Text UI as opposed to using the Web UI
for configuring the IP Series is that with the Text UI there is no need
to concerned with the unit's IP address or subnet.
There are some subtle differences in configuring the IP Series
using the Text UI. The following steps pertaining to configuring the
Radio portion of the unit will highlight those differences:
CONFIDENTIAL
IP9xx Series
All options presented within the
continued...
152
