6.0 Configuration
© Microhard Systems Inc.
This field allows for the rule to be applied to either a Custom
Service (defined further down the menu) or for one of many
predefined services available via a pulldown menu.
If a valid IP address is specified, the action will apply against that
address; otherwise, leaving the default value of 0.0.0.0 in this field
results in the action applying to all destination IP addresses.
This field is configured if defining a Custom Service (ref. Select
Service field).
CONFIDENTIAL
IP9xx Series
Select Service
Values
Custom Service
or select from a long listing
of predefined services
Destination IP
Values
0.0.0.0
valid IP address
Destination Port
Values
0
valid port number
