6.0 Configuration
6.1.4.7 VLAN (Continued)
In the example below, The VLAN feature can be used to filter data so that only the data
between the IP Phones (VLAN3) are transmitted on the wireless link.
© Microhard Systems Inc.
Computer (VLAN2)
IP Phone (VLAN3)
Use the VLAN Status option to enable or disable the VLAN
functionality on the radio. The default value is disable.
Once VLAN us enabled, it uses a default value of 1 for the
Native VLAN for management purposes.
Serial Data
(Untagged)
Example
CONFIDENTIAL
IP9xx Series
IP Phone (VLAN3)
VLAN Status
Values (selection)
Disable / enable
Management VLAN (VLAN ID)
Values
1
