Completing Installation and Cabling of the CTS 1100
Step 9
Connect the microphone to its tray by placing each microphone on its tray and attaching it with the
screws.
Do not use the longer 60mm screws that are included in the kit. Use the correct M4 x 10 screws as
Note
specified in
Figure 3-43
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-54
Table
3-1.
Attaching the Microphone to the Microphone Base
Chapter 3
Assembling and Mounting a Cisco TelePresence System 1100
28
28
26
27
OL-19695-01
