Assembling and Mounting a Cisco TelePresence System 1100
Step 7
Secure the light reflector to the wall by completing the following steps:
a.
b.
Figure 3-26
Securing the Light Reflector to the Wall Using Screws and Washers
OL-19695-01
Perform one of the following actions, depending on your wall type:
For a wall that uses steel or wooden studs, insert anchors in each drilled hole by completing
•
Step 6
through
Step 9
section on page
3-14.
•
For a concrete, concrete block, or brick wall, insert anchors in each drilled hole by completing
Step 1.b.
in the
"Attaching the Mounting Bracket to a Concrete, Concrete Block, or Brick Wall"
section on page
3-21.
Secure the light reflector to the wall with the screws and washers.
4
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
in the
"Attaching the Mounting Bracket to a Wall With Steel Studs"
3
Attaching the Light Reflector, Display, and Cabinet
3-33
