Cisco TelePresence System 1100 Assembly Manual page 24

Parts List
Table 3-1
Key Part Description
10 Screw included with the 1/4-20 Snap Toggler BB Anchor Included with Mounting Kit
11 Buttons and hex screws for mounting display
12 Display
13 Display mounting plate
14
10mm drill bit for concrete, concrete block, or brick
installation
15
10 x 60 mm anchor
16 #8 x 1/4-inch self-tapping screw
17
Camera processors
18 Codec
19 Bezel
20 Camera assembly
21
Speaker cover
22 Bezel connecting tube
23 Bezel clip
24 Cap Nut
25 Compliance Label
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-6
Parts List for CTS 1100 and Associated Mounting Hardware (continued)
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
Part Number
(Cisco Part Number
74-6567-01 or Chief UL
Listed Part Number
MSP-CSC6)
Included with Mounting Kit
(Cisco Part Number
74-6567-01 or Chief UL
Listed Part Number
MSP-CSC6)
CTS-DISP-65-GEN3
Cisco Part Number
74-6567-01
or
Chief UL Listed Part Number
MSP-CSC6
Not included
Included with Mounting Kit
(Cisco Part Number
74-6567-01 or Chief UL
Listed Part Number
MSP-CSC6)
Included with Mounting Kit
(Cisco Part Number
74-6567-01 or Chief UL
Listed Part Number
MSP-CSC6)
800-32491-01
CTS-CODEC-PRI-G2
CTS1300-DISP-BZL
CTS1100-CAM
CTS1300-SPKR-COV
Included with
CTS1300-DISP-BZL
Included with
CTS1300-DISP-BZL
Included with
CTS1300-DISP-BZL
47-22285-01
Qty Ctn Notes
16 2
6 2
1 5
1 2
1 Required for
masonry
installation
16 2
4 2
3 11
1 7
1 8
1 11
1 9
4 8
4 8
8 8
1 1
OL-19695-01
