Cisco TelePresence System 1100 Assembly Manual page 30

Attaching the Mounting Bracket to a Wall With Wooden Studs
Step 7 Attach the mounting bracket to the studs and wall using the following fasteners:
a.
b.
Arrange the bracket so that the row of holes are on top as shown in
Note
arrange the bracket so that the arrows on the vertical cross-pieces point upwards.
Figure 3-6 Attaching the Mounting Bracket to the Wall
10
4
4
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-12
Use 5/16-inch lag screws and washers for the four holes that go into the studs. Make sure that the
bracket is level. At least two screws must go into studs.
Use the toggle bolts for the two outside holes that are not required to go into the stud.
3
3
4 3
3
4 3
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
10 3 2
Figure 3-6. If the bracket has arrows,
OL-19695-01
