Chapter 6
Field-Replaceable Unit Guide
Figure 6-7
Power and Signal Connections for Displays with DVI Connectors
Replace the bezel.
Step 12
See
Replace the speaker cover.
Step 13
See
Power on the system by turning the power switch on the PDU inside the cabinet to the "ON" position.
Step 14
Step 15
Replace the cabinet cover.
OL-19695-01
AC inlet
Figure 3-38
for more information.
Figure 3-42
for more information.
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Replacing the Display—Part Number CTS-DISP-65-GEN4=
On/Off Switch
Codec DMP
6-17
