Chapter 3
Assembling and Mounting a Cisco TelePresence System 1100
Attaching the Light Reflector, Display, and Cabinet
Step 9
Place the camera processor into its holder in the light reflector and connect the Ethernet and video cables
to the processor.
Tip
The processor and cables are labeled. Use these labels to match the cables to the processor.
Figure 3-29
Camera Processors and Light Reflector
17
17
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-36
OL-19695-01
