Completing Installation and Cabling of the CTS 1100
Step 6
Attach the camera to the assembly by completing the following steps:
Slide the camera assembly into the metal tab above the display.
a.
Secure the camera to the assembly by screwing in the center cluster attachment screw.
b.
Secure the camera cables to the processors
Step 7
The camera and cable is labeled; use this label to match the cable to the camera.
Tip
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-50
Chapter 3
Assembling and Mounting a Cisco TelePresence System 1100
OL-19695-01
