Cisco TelePresence System 1100 Assembly Manual page 60

Attaching the Light Reflector, Display, and Cabinet
Step 15 Using two people, install the cabinet by completing the following steps:
Lean the cabinet so that the top part of it leans toward the wall.
a.
Route the cables through the center slot on top of the cabinet.
b.
Slide the lower part of the cabinet so that it sits flush against the wall underneath the light reflector.
c.
Note
If you encounter clearance problems between the light reflector and the cabinet, rotate the screws on the
Tip
cabinet feet until the cabinet is at its minimum height.
d. Install anchors to the wall in preparation for installing toggle bolts by performing the following
actions:
1.
2.
3.
4.
5.
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-42
Do not pinch any cables between the cabinet and the wall.
Mark holes through the slots on either side of the upper part of the cabinet. See
the location of the holes. You can use any of the slots on each side.
Remove the cabinet.
Drill two 1/2-inch holes, using the marks you made in Step
insert anchors into the drilled by completing
Mounting Bracket to a Wall With Steel Studs" section on page
Replace the cabinet so that it sits flush against the wall underneath the light reflector.
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
1.
Step 6 through Step 9
Figure 3-35
as a guide.
in the "Attaching the
3-14.
OL-19695-01
for
