Attaching the Mounting Bracket to a Concrete, Concrete Block, or Brick Wall
Measure and drill the holes in the wall by completing the following steps:
Step 1
a.
Note
Use a level on the bracket when you measure the holes. Leveling the holes ensures that the bracket is
Tip
horizontally level when it is mounted.
Figure 3-16 Measuring Holes in the Wall for the Mounting Bracket
from floor to
center of holes
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-22
Using the mounting bracket as a template and
into the wall.
Arrange the bracket so that the row of holes are on top as shown in
the bracket upside down, the mounted parts of the CTS 1100 will be too high on the wall. If the
bracket has arrows, arrange the bracket so that the arrows on the vertical cross-pieces point
upwards.
16 in.
(40.6 cm)
55 in.
(140 cm)
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
Figure 3-16 as a reference, measure six 10mm holes
16, 20 or 24 in.
Width between stud holes can be
16", 20" or 24".
Make sure these holes are level.
Floor
Figure 3-16. If you mount
