Chapter 3
Assembling and Mounting a Cisco TelePresence System 1100
Step 10
Remove the display from its packaging.
Remove the screws that attach the handles and universal mounting bracket to the rear of the display, then
Step 11
remove the handles and bracket.
Figure 3-30
Removing the Hardware from the Rear of the Display
12
OL-19695-01
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Attaching the Light Reflector, Display, and Cabinet
3-37
