Attaching the Mounting Bracket to a Wall With Wooden Studs
Step 6 Insert anchors for the two outside holes (the holes that you drilled with a 1/2-inch drill bit) by completing
the following steps:
a. Using the anchors that are provided in the accessory kit, move the plastic straps on the anchor until
the metal part of the anchor is parallel with the straps.
b. Push the metal part of the anchor through the two outside holes that you drilled.
Figure 3-3
Turn the plastic straps on the anchor so that the metal part of the anchor is flush and vertical to the
c.
inner part of the stud or wall.
d. Slide the plastic cap on the anchors until the cap is flush with the outer part of the wall.
Figure 3-4
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-10
Pushing the Anchor Through the Wall and Stud
1
Securing the Anchor and Cap to the Wall
Plastic Cap
1
Anchor Metal Channel
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
Metal Stud
Drywall
(Side View)
Hole drilled
in drywall
