Cisco TelePresence System 1100 Assembly Manual page 44

Attaching the Mounting Bracket to a Concrete, Concrete Block, or Brick Wall
Step 5 Move the sliders and strips so that they align as closely as possible with the center of the table.
Using duct or other tape, tape the strip between the sliders into the slot in the bracket.
Step 6
Tip The tape prevents the sliders from moving when you install the light reflector.
Figure 3-20 Centering the Studs and Strips to Accommodate Table Placement
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-26
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
Bracket Sliders
Table
Bracket Sliders
Table
OL-19695-01
