Chapter 3
Assembling and Mounting a Cisco TelePresence System 1100
Step 6
Insert the mounting anchors into the holes that you drilled by completing the following steps:
a.
b.
Figure 3-10
Pushing the Anchor Through the Wall and Stud
Step 7
Turn the plastic straps on the anchor so that the metal part of the anchor is flush and vertical to the inner
part of the stud or wall.
Step 8
Slide the plastic cap on the anchor until the cap is flush with the outer part of the wall.
Figure 3-11
Securing the Anchor and Cap to the Wall
1
OL-19695-01
Using the anchors that are provided in the accessory kit, move the plastic straps on the anchor until
the metal part of the anchor is parallel with the straps.
Push the metal part of the anchor through the stud hole that you drilled.
1
Metal Stud
Drywall
Plastic Cap
Anchor Metal Channel
(Side View)
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Attaching the Mounting Bracket to a Wall With Steel Studs
Hole drilled
in drywall
3-17
