Assembling and Mounting a Cisco TelePresence System 1100
Attaching the Light Reflector, Display, and Cabinet
Step 12
Attach the mounting buttons to the rear of the display.
Do not use power tools to attach the screws, you could overtighten the screws and damage the buttons.
Note
Tighten the screws by hand until they are hand tight.
You use these buttons to hang the display onto the display mounting plate.
Figure 3-31
Attaching the Mounting Buttons to the Rear of the Display
11
34
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-38
OL-19695-01
