Attaching the Light Reflector, Display, and Cabinet
Step 6 Using holes in the light reflector as a template, drill holes around the perimeter of the light reflector. Use
one of the following drill bits, depending on your wall type:
•
Note
•
Use the holes in the light reflector as a template for the holes that you drill.
Figure 3-25 Drilling Holes For Light Reflector Anchors
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-32
Use a 1/2-inch drill bit for walls with wooden or steel studs.
To drill the top two holes, you need a drill bit that is at least 6 inches (15 cm) long.
Use a 10mm masonry bit for concrete, concrete block or brick walls.
Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
