Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
Attaching the Light Reflector, Display, and Cabinet
Step 13 Using at least two people (one person on each side of the display and one person in the center of the
display), lift the display and hang the six buttons over and into the keyhole slots in the mounting plate.
Tip Align the Cisco logo on the top center of the display with the center positional microphone in the top
center of the light reflector. View the display from the side and make sure that all buttons are engaged
firmly in the bracket.
Take care to not pinch your fingers between the display and the metal brackets on the light reflector;
Warning
these brackets fit very closely to the display.
